In the Schwerkraftmaschine, the signal passes through a total of three transformers and four triode tubes per channel.
Why does this matter? Tubes, and especially triodes, add harmonic overtones to the signal that the human ear finds pleasing while improving our perception of individual sounds.
The individual instruments are given additional presence through the tubes.
Through the conversion of electricity into magnetic fields and back to electricity, the transformers and their non-linearities increase the density of the sound before it is compressed.
The bass becomes cleaner and more defined. The high frequencies are pleasantly rounded.
- Stereo device
- Transformer balanced inputs and output
- Frequency response: 20 – 40,000 Hz +/- 1.5dB
- Vari-Mu Compressor
- Digital side-chain
- 11 Compression modes – Multi-Band Complex, Diode Pressor, Breakthrough, Stereo Transformer, Vari Tube Compressor, Vocal Leveler, Optical Compressor, Drum Smasher, Classical VariMu, Chart Analysis, and De-Esser
- Side-chain filter as Low-cut from 0-300 Hz or tilt filter
- Controllable by the webpage of the device or by plug-in (VST, AU, AAX)
- Servo Pots
- Dynamic: >110dB unweighted
- Attenuation-to-crosstalk ratio L/R >90 dB @ 1 kHz
- Internal Power Supply (25W)
- Height: 132mm (3U), Width: 483mm, Depth: 250mm
- Frequency Response: 20Hz - 24kHz
- Maximum Input Level: +20 dBu
- Input Impedance: ≥ 2.4kΩ
- Output Impedance: < 600 Ω
- Maximum Output Level: +24 dBu
- Dynamic Range: ≥ 101 dB
- Voltage: 110- 240 V~/50-60 Hz
- Fuse: 2A slow-blow
- Maximum Power Consumption: < 25 W
- Dimensions: 3 U, H:132 mm, W:483 mm, D:250 mm
